| 一、Vehicle parameters | ||||
| Parameter item name | Value of parameter item | |||
| Dimensions (length x width x height) mm | 2070×820×11301220 | |||
| Wheelbase mm | 1335 | |||
| Minimum ground clearance distance mm | 290 | |||
| Seat cushion height mm | 895 | |||
| Operate the turning angle (left/right) | ≤42° | |||
| Minimum turning radius mm | 1850 | |||
| Final transmission ratio | 13/45 | |||
| Climbing slope | 25° | |||
| SEATS | 2 | |||
| Shift mode | Five international levels | |||
| Fuel tank capacity L | 8 | |||
| fuel type | 92 octane gasoline | |||
| Rated maximum load mass Kg | 150 | |||
| Vehicle dry weight kg | 122 | |||
| Vehicle curb weight Kg | 130 | |||
| Factory determined maximum total load weight Kg | 280 | |||
| Maximum speed (km/h) | 106 | |||
| Braking performance m | ＜7m | |||
| Starting performance S | ＜15 | |||
| Economic fuel consumption L/100Km | 2.4 | |||
| Braking method | front wheel | disc | ||
| rear-wheel | disc | |||
| Braking operation mode | front wheel | hand | ||
| rear-wheel | foot | |||
| Wheel rim type | Net wheel | |||
| Rim Specifications | First 1.85 × 21; Rear 2.15 × 18 | |||
| Tire specifications | Internal and external tires | |||
| Tire Size | 90/100-21、 110/90-18 | |||
| Tire pressure (front/rear) Kpa | (Former) 280; (Later) 280 | |||
| Specification and illuminance of large light bulb | 12V-35W/35W ≥10000cd | |||
| Battery specifications and external dimensions (length x width x height) mm | MTX7L-BS/semi maintenance free battery 114 × 70 × 130 | |||
| 二、Engine parameters | ||||
| engine type | Single cylinder vertical 15 °, air-cooled, SOHC-2V two valve, built-in balance shaft | |||
| Magnetic motor type | 12V/12 pole/full wave DC | |||
| Travel distance mm | 64.6 | |||
| Cylinder diameter mm | 73 | |||
| Cylinder working volume ml | 270.4 | |||
| Compression ratio | 9.2:1 | |||
| Fuel grade | 93 octane gasoline | |||
| Total oil capacity L | 1.5 | |||
| Spark plug model | D8RTC/D8REA | |||
| Spark plug gap mm | 0.6～0.7 | |||
| Valve clearance mm | 0.03～0.05 | |||
| Start mode | Electric starter/foot starter | |||
| Lubricating oil grade | SAE 10W/40 | |||
| Lubrication method | Pressure splash lubrication | |||
| Ignition method | C.D.I | |||
| carburetor type | PEn30 | |||
| Carburetor type | plunger type | |||
| Transmission type | fifth gear | |||
| Clutch type | Multi piece oil bath/manual clutch | |||
| Primary transmission ratio | 2.9167 | |||
| Variable speed ratio | i1=3.0,i1=2.701，i3=1.529,i4=1.15，i5=0.954 | |||
| Output transmission mode | chain drive | |||
| Output shaft rotation direction | Facing the output shaft, rotate counterclockwise | |||
| Dimensions (length x width x height) mm | 360×350×430 | |||
| Net weight Kg | 33±0.5 | |||
| Maximum advance angle of magnetic motor ignition | 30 ° before the top dead center | |||
| Maximum net power and corresponding speed kW (r/min ± 5%) | 16.8Kw/7500rpm | |||
| Maximum torque and corresponding speed N.m (r/min ± 5%) | 23N.m/6500rpm | |||
| The minimum fuel consumption rate is less than g/Kw. h | ≤343 | |||
