| 一、specification | ||||
| English item | specification | |||
| Overall dimension (length × wide × Height) mm | 1920×800×1210mm | |||
| Wheelbase mm | 1240 | |||
| Minimum ground clearance mm | 130 | |||
| Seat cushion height mm | ||||
| Operating handle return angle (left/right) | ≤48° | |||
| Minimum turning radius mm | 2200 | |||
| Final transmission ratio | 11:36 | |||
| Climbing slope | ≥20° | |||
| Seats | 2 | |||
| Shift mode | Four-speed semi-rotation | |||
| Fuel tank volume L | 0.8 | |||
| Fuel type | 90# | |||
| Rated maximum load kg | 150 | |||
| Net weight kg | 90 | |||
| Curb weight Kg | 95 | |||
| Maximum load total kg | 245 | |||
| Maximum speed Km/h | 85 | |||
| Braking performance m | ≤7m/30km/h | |||
| Starting performance S | ≤15S | |||
| Rated power Kw/r/min | 5.5KW/7500±500r/min | |||
| Economic fuel consumption L/100Km | 2.1 | |||
| Brake | front | Front plate/drum | ||
| rear | Drum brake | |||
| Brake operation | front | Hand brake | ||
| rear | foot brake | |||
| wheel | Net/aluminum wheel | |||
| spoke wheel size | front：1.4×17 rear ：1.6×17 | |||
| tyre | Ordinary tyre | |||
| tyre size | front：2.50-17 rear：2.75-17 | |||
| Tyre pressure (front/rear) Kpa | 225Kpa | |||
| Specification and illumination of large bulb | 12V-35W/35W ≥10000cd | |||
| Steering bulb specification | 12V-10W | |||
| Battery specification | ||||
| 二、 ENGINE SPECIFICATION | ||||
| Engine type | Single cylinder, four stroke, natural air cooled, oblique, lower CAM | |||
| Magneto type | 12V/level 6/full wave, | |||
| Stroke mm | 49.5 | |||
| Cylinder diameter mm | 52.4 | |||
| Working volume of cylinder ml | 106.7 | |||
| Compression ratio | 9.0：1 | |||
| Fuel grade | 90 # gasoline | |||
| Total oil capacity L | 0.8 | |||
| Spark plug model | A7TC | |||
| Spark plug gap mm | 0.6～0.7 | |||
| Valve clearance mm | 0.04±0.07mm | |||
| Starting mode | Electric start/kick start | |||
| Lubricating oil grade | 15W/40 | |||
| Lubrication method | Splash pressure lubrication | |||
| Ignition mode | C.D.I | |||
| Carburetor model | PZ19 | |||
| Carburetor type | Horizontal suction plunger type | |||
| Transmission type | Constant mesh two-stage transmission and five-speed transmission | |||
| Clutch type | Multi-disc oil bath manual clutch | |||
| Primary gear ratio | 4.059 | |||
| Gearshift ratio | i1=2.833 ,i2=1.706.i3=1.238,i4=0.985 | |||
| Output transmission mode | Chain drive | |||
| Rotation direction of output shaft | Face the output shaft and rotate counterclockwise | |||
| Overall dimension (length × wide × Height) mm | ||||
| Net mass Kg | ||||
| Magneto ignition advance angle | 15º | |||
| Rated power and corresponding speed kW (r/min ± 5%) | 5.5KW/8000±500r/min | |||
| Maximum net power and corresponding speed kW (r/min ± 5%) | ||||
| Maximum torque and corresponding speed N.m (r/min ± 5%) | 7N.m/5000±500r/min | |||
| The minimum fuel consumption rate is less than g/Kw. h | 367g/KW.h | |||
