Parameters

一、Technical data
dimension		1920×650×1050	fuel tank vol	3.8
wheel base		1210	fuel size	90#
(mm)ground distance		130	spark sixe	A7TC
brake distance		≤7m/30km/h	spark gap	0.6～0.7
start time		≤15s	clutch type	Single clutch
Vehicle mass		90	lubrication	Pressure splash lubrication
standard loading		145	lubrication oil vol	0.8
Max speed		80	valve gap	Into the：0.03，row：0.05
min fuel cons.		≤1.2	engine model No	153FMH
brake type		Fore and aft drum	engine type	Horizontal, single cylinder, four stroke, air cooled
start type		Electric/pin start	bore*stroke	52.4*49.5
tyire size		before：2.25-17 after;2.50-17	compress ration	9.0：1
tyire pressure		before:220, after:280	displacement	106.7
climb		≥18°	standard power	4.1KW/8000±500r/min
start type		C.D.I	Max torque	6.2N.m/5000±500r/min
seat height		730	other velocity ratios	i1:2.833
				i2:1.706
Primary Velocity ratio		4.059		i3:1.238
				i4:0.958
				i5:/
二、Optional configuration
	EEC,DOT,EPC,CCC		Double lamp
	50CC,100CC,110CC,120CC,127CC,124CC
	The front disc and the back drum
	Liquid crystal instrument
